Watch the Autek IKey820 Key Programmer do it's thing on a Mazda 3 | Key Programming

Watch the Autek IKey820 Key Programmer do it's thing on a Mazda 3 | Key Programming

Add a key to a 2005 Mazda 3 like a LockBoss using the Autek IKey820 Key Programmer. Look up the PDF guide to gather information and make sure that you could do it. Also, duplicate the existing key onto the JMA MAZ34 PT. Check to see if it works.

Autek Ikey820 Key Programmer

Prepare the things needed and connect the Autek machine to the OBD2 port.

Conncect the Autek Ikey820 Key Programmer to the OBD2 port

Turn the machine on and go to the key program. Look for the model, which is Mazda. Hit OK, and then we'll go By Vehicle. Choose Mazda 3, and select 2005. Once done, hit OK.

Key programming with the Autek Ikey820

Key (Type 1), Key (Type 2), will appear, so go with Type 1. Wait for a while, then take the new key. Insert the key and turn it on. Once you have it on, I'll hit OK.

Pick a key type on the Autek Ikey820 Key Programmer

Wait for a while, and once connected, select Add key and hit OK. ‘Change the new key and turn the ignition on.’ since you’ve done that, skip and hit OK. It’s a Failure.

Add a key on the Autek Ikey820 Key Programmer

Autek Ikey820 Key Programmer

Alright, no problem, go back and choose the Key (Type 2). Loading the database, turn the ignition on, and hit OK. Again, choose Add Key, hit OK. ‘Change the new key and turn the ignition on’ will appear. This time turn it back off, then back on real quick, and hit OK. It’s a Success.

For each programming done, you should test out the keys and be sure to hear the locks cycle. Compare the function of your newly programmed keys with the original key to be sure that everything is still working. You can try to start your ignition and controls with the new programmed key to ensure it is both working.

And that is how you make an extra key for a 2005 Mazda 3 with the Autek IKey820 Key Programmer. Thank you, and we'll see you next time!
