How It Works: Privacy Function on Commercial & Residential | Video



Locks with a privacy function come in all grades including; Grade 1, Grade 2 and Grade 3 depending on the environment in which they are being installed (ie. residential, business or heavy commercial) Learn how the privacy function works and how it is used by viewing the video above or reading below.

Specifications:



INTRODUCTION

To review, let’s take a look at the technical features and specifications of a common Level 1 commercial privacy function. You can view this product in our store here.

Features:

  • ANSI Grade 1
  • ADA compliant ANSI A117.1 Barrier Free Accessibility
  • UL 3 hours Fire Rating UL10C/UBC 7-2(1997) Positive Pressure Rated
  • CALIFORNIA STATE REFERENCE CODE
  • Formerly Title 19,California State Fire Marshal (CSFM) levers return to within 1/2” of door face
  • Independent torsion springs
  • Fast and easy installation
  • Clutch function standard
  • Removable through bolt
  • Panic proof (inside always free)
  • Concealed Mounting Screws
  • Lifetime Mechanical Warranty

Specifications:
  • Door Fitting: 1-3/8” ~ 2” door thick. Factory preset at 1-3/4”. Thru-Bolt CTC: 2-3/4”.
  • Exposed Trim: Wrought brass. Pressure cast zinc lever.
  • Lock Chassis: Heavy gauge dichromated steel. Zinc dichromated for corrosion resistance.
  • Latch: 2 3/4" Backset 1/2” throw, 7/8” dia. stainless steel latch bolt. 1-1/8” x 2-1/4” faceplate. Floating latch design fits both flat or beveled doors 1/8” in 2”.
  • Strike: ASA strike standard
  • Handing" Universal, non-handing.
  • Screws: Combination screws for both metal and wood doors.

HOW A LOCK PRIVACY FUNCTION WORKS

Privacy lock sets are often used for commercial restrooms or dressing rooms, although they do have uses that range all the way from residential to heavy commercial (Grade 1, Grade 2 & Grade 3). In short, a privacy function lock has a clutch that allows a door to be locked and unlocked only from the inside.

Privacy Lock Function - CLK Supplies

Privacy locks sets are not meant to provide security. The primary function of a privacy lock is to let an individual enter a space and allow them to close the door and lock it behind them so that they are not disturbed from the outside for a short time. On the inside of the door lockset, a push or turn button that allows the individual to easily lock the door. A quick turn of the handle unlocks the door when the individual is ready to leave the room.

On the outside of a door installed with a privacy function there is no key lock mechanism. Instead, the lockset has a small raised surface that contains a hole or slot. This a safety feature that allows the door to be opened with a coin, or tool like a flat head screwdriver if it is shut without an individual inside the door to open it.

How to unlock privacy lock

Although restrooms and fitting rooms are the most popular applications for a privacy function, they do come in other variations such as those commonly used in hospitals that offer a thumb-turn on both the inside and outside of the door in case hospital staff needs to quickly access a patient. Another variation includes an indicator on the outside of the door that tells whether the room is “Occupied” or “Vacant.”

You can view and share the full video for this post on YouTube here: https://www.youtube.com/watch?v=4_KFstz_v7Y&t=1s



Don’t forget to like and subscribe to our channel where we upload new tutorials on locksmithing every month.

VIDEO TRANSCRIPT:


PJ: Hey, this is PJ with CLK Supplies and this is the privacy lock function. Now the privacy lock function is found on grade one, two, and three hardware meaning it's found between the basic residential all the way to heavy duty commercial. Now just like its name, this lock is meant to provide privacy, not security. And what do I mean by that? It means on the outside of the lock, as you can see here, there's a little turn piece where like a normal lock cylinder would go. Okay. Now depending on who makes it and what grade it is, it may have like a little hole here with like you could stick a paperclip in and push it. In this case it has this little turn piece, which you can use just about anything you could use like a quarter. As you can see here, just like that. Or you could use a screwdriver or you could use even the corner of a credit card if you needed. All right, so it's just meant to provide privacy, not really security.

PJ: All right. Now on the inside, you're going to find on this one, there's going to be a push button. Sometimes there'll be a little twist knob depending on the grade and what the manufacturer used here, but they're all going to work about the same way. On the inside you're going to lock it, which in this case you're just going to push it in here. And on this one, if you pull down, it's going to pop open, or if you pull up, it's going to pop open. And from the outside when the button's pushed, this is a clutch function, which I'll put in the notes below. If you don't know what that is, when you pull this lever down, it's not going to activate the lock, right? But as soon as you open the door from the inside, this button's going to pop out. Now it's going to be unlocked. So it's perfect for a bathroom setting, a fitting room setting, anything where you just want to get some privacy and you're not really looking for security. So this is the privacy function. Thanks for watching. We'll see you next time.
