Commercial Knob Storeroom Grade 2 US32D 2 3/4"

by PHG
$ 33.05
SKU EZ333622

Commercial Knob Storeroom Grade 2 US32D 2 3/4"

Applications For offices, schools, hospitals, apartments, hotel/motel and other public buildings. Door Ranges 1-3/8” ~ 1-3/4” door thickness. Backset 2-3/4”(70 mm) standard Front 2-1/4” ~ 1-1/8”, adjustable for flat or beveled doors 1/8” in 2”. Strike Standard "T" strike (9106). 1-1/8" x 2-3/4" x 5/64" square corner. Latchbolt 1/2" throw stainless steel latch bolt. 2-3/4" backset - 1-1/8" x 2-1/4" faceplate mortise latch. 2-3/8" backset - 1" x 2-1/4" faceplate mortise latch. ANSI Grade II Standards Meets or exceeds requirement of BHMA/ANSI A156.2, 400,000 cycles. Exposed Trim Wrought brass or stainless steel. Pressure cast zinc lever. Keying 6-pin tumbler cylinder, 2 keys per lock. Keying job is available upon request. Features SC4 Keyway, concealed mounting screws, fast and easy installation, 1 PCS High Security Knob.
