When it comes to door security and controlled exits, the Detex EAX-500 Exit Alarm (and its sibling, the EAX-300) is a must-have for professional locksmiths, security technicians, and facility managers. These alarmed exit devices prevent unauthorized exits while ensuring quick egress during emergencies, a perfect solution for commercial doors, retail stores, and secure facilities.
In this step-by-step guide, we’ll walk you through how to install the Detex EAX-500 Exit Alarm like a pro, highlighting key installation tips and sharing where you can find reliable locksmith tools and Detex hardware, all available at CLK Supplies.
An exit alarm, also known as a door exit alarm or exit door alarm, is a security device designed to alert building staff or security personnel when an emergency exit door is opened without authorization.
Before diving into the installation, it’s worth knowing why the Detex EAX-500 is such a popular choice among locksmiths and security professionals:
Tamper-resistant design prevents unauthorized removal.
120 dB alarm alerts when the door is opened without authorization.
Self-contained battery-powered unit—no hardwiring required.
Compact and durable, this construction is suitable for both wood and metal doors.
Easy to fit installation, even for beginners.
When properly installed, the EAX-500 Exit Alarm serves as a powerful deterrent against theft and unauthorized exits, providing peace of mind in high-traffic environments.
Here is the step-by-step guide for locksmiths on how to install an exit alarm lock:
If you’re replacing an existing Detex Alarm Lock or exit alarm, start by removing the current unit. Use your service key to open the housing and unscrew the mounting screws carefully. Inside, you’ll find the battery compartment and mounting plate.
Take note of the door gap distance when opening and closing the door. This is important for correct magnet placement later. On many wooden doors, the gap is small, so accuracy here ensures the alarm will function properly.
The Detex EAX-500 kit includes a mounting plate and a magnet assembly. Before drilling, use a marker to mark the locations of your mounting holes: two for the plate and two for the magnet. You can use a level to ensure straight alignment.
If you’re installing on a wooden door, standard wood screws will suffice. Drill pilot holes first to avoid splitting. Secure the mounting plate (with “TOP” facing up), then attach the magnet to the corresponding position on the frame.
Pro Tip: Check the gap between the magnet and the alarm unit when the door closes; it should be small but not touching. Misalignment can prevent the alarm from triggering properly.
Open the battery compartment and insert the included 9V battery. You’ll hear a quick beep confirming power. According to the manufacturer’s guide, make sure the connector is firmly seated. This ensures proper functionality and alarm readiness.
CLK Supplies recommends keeping spare 9V batteries in your locksmith toolkit, as the Detex alarm relies on consistent battery power to maintain peak performance.
Now, align the main alarm unit with the mounting plate and secure it in place using the provided cam lock (service access key). Once attached, verify that the magnet is properly aligned by opening and closing the door.
If the alignment is off, adjust the magnet slightly. Don’t worry, it’s common to reposition during installation. The goal is a clean fit that triggers the alarm when the door opens.
When everything looks good, switch the alarm to “ON” mode. Wait for the LED lights to go out. This indicates it’s armed and ready.
Now, test it by opening the door. The loud 120 dB alarm should sound immediately, a clear sign your installation is successful!
If your Detex exit alarm isn’t functioning as expected, don’t worry, most issues are easy to fix with a few quick checks.
No sound after arming? Ensure that the battery is securely connected and the magnet is properly aligned with the sensor. A weak or loose connection can prevent the alarm from activating.
Alarm too sensitive? The magnet might be placed too close to the unit. Adjust its position slightly to prevent unnecessary triggers.
Loose mounting plate? Use screws suitable for your door material (wood, metal, or composite). This ensures stability and proper alignment.
Always read the installation manual included with your Detex exit alarm before beginning. Keeping your workspace organized and following the step-by-step guide can save time and help avoid common installation mistakes.
At CLK Supplies, locksmiths and security pros will find everything needed for Detex installations, including: Detex EAX-500 and EAX-300 exit alarms, cam locks, service keys, screwdrivers, drill bits, alignment tools, and many other locksmith installation accessories.
CLK Supplies provides fast shipping, competitive prices, and trusted brands, making it the go-to source for professional locksmith supplies.
Installing the Detex EAX-500 Exit Alarm is quick, reliable, and adds a crucial layer of security to any exit door. Whether you’re upgrading an old system or installing a new one, following the proper steps ensures top-notch results.
For premium locksmith tools, exit alarms, and hardware essentials, visit CLK Supplies, your trusted partner in professional locksmithing.
The Detex EAX-500 is designed to sound an alarm when a protected door is opened without authorization. It’s ideal for retail stores, offices, and commercial facilities that want to prevent unauthorized exits.
Typically, the 9V battery in the EAX-500 lasts between 6 to 12 months, depending on usage. Regularly test and replace the battery as part of your maintenance routine.
Yes. The unit can be installed on both wood and metal doors using appropriate screws and anchors. Always check for a flush surface before mounting.
No specialized tools are required. A drill, screwdriver, level, and marker are sufficient for most installations. However, professional locksmiths often prefer using precision tools from CLK Supplies for accuracy.
Ensure the battery is correctly connected, the magnet is aligned, and the alarm is armed (ON position). If issues persist, replace the battery or consult the installation manual.
