Answer
Jul 21, 2026 - 02:44 PM
The correct way to dimension a keyway is to specify its width, depth, and position relative to a reference surface, such as the end or centerline of the shaft or hub. Dimensions should be clearly indicated on the drawing, typically using standard symbols and tolerances as per engineering drawing conventions (e.g., ISO, ANSI).
